YBD164
EBD
1. Jumbo rotary hook for the bottom thread reduces a lot of times for changing the bobbins.
2. Integrated structure machine frame makes sure the machine running stably with high speed.
3. Quilting speed can maintain 800RPM without decreasing when stitch step is within 5mm,
4. Synchronized driving structure roller system can guarantee the product quilting precision without adjusting the rollers while quilting the materials with various thicknesses
5. Unique driving structure can guarantee the rollers rolling smoothly and stably during machine running.
6. 10 inches(Can customize 15inches) touch screen control system makes the machine operation easier and simpler.
7. The screen can read and display the complete patterns, and the patterns can be edited on it
8. Each page of the operating system is with help function, new operator can operate the machine in a short time after reading the help pages that saves the staff training time.
9. Intelligent head lock embroidery function is optional.
10.Automatic winding and fabric feeding devices are optional.
Specifications/parameters
Product Model | YBD164 | Remarks |
Needle Numbers | 64 needles | |
Needle Gap | 50.8mm | |
Maximum travel in the X-axis direction | 254mm | |
Working Width | 1620mmX2 | The working width is the width of machine quilting but the width of fabric fed |
Stitch Step | 2mm-12mm | |
Speed | 800-1000 R.P.M | |
Needle Size | 12*-18* | |
Voltage | AC220/380V.50Hz | |
Power | 6KW | |
Machine Size | L5765*W1567*H1832(mm) | After removing the feeding bracket: L1156mm, H1567mm |
The needle gaps can be customized to be 67.5mm ,76.2mm. | ||
Suitable for：garment, furniture, hand bag, car seat cover, shoe and so on.
